Description
Advanced Cell Balancing ≥8000 Cycles Support remote OTA upgrade and remote maintenance. Local and remote management, standard rack & module design, front maintenance full-time balancing technology ensures battery consistency and extends service life Self-developed 2-level/3-level BMS Multiple Protection, Safe And Reliable
Specifications
| Model | YF-LFP-HV-7 |
| Battery Type | LiFePO4 |
| Module Energy | 11.7kWh |
| Single Module Nominal Voltage | 51.2V |
| Module Capacity | 230Ah |
| Number of Battery Modules (Optional) | 7 |
| System Energy | 81.9 kWh |
| System Nominal Voltage | 358.4 V |
| System Operating Voltage | 336—403.2V |
| Scalability | Max.8 PCS in Parallel(1404 kWh) |
| Recommend Charge/Discharge current | 80A |
| Max.continuous charge/Discharge current | 100A |
| Peak Charge/Discharge Current(@2s) | 125A |
| Depth of Discharge(DOD) | 90% |
| Display type | LCD(Touch) |
| Protection Level | IP21 |
| Operating Temperature Range(Charge) | 0°C ~ +50°C |
| Operating Temperature Range(Discharge) | -5°C ~ +50°C |
| Storage Temperature Range(One month) | -10°C ~ +45°C |
| Storage Temperature Range(Six months) | -10°C ~ +35°C |
| Humidity | 20%~95%(No condensation) |
| Altitude | ≤2000m |
| Cycle Life | ≥8000 Cycles |
| Cooling Method | Natural cooling |
| Installation | Rack-Mounting |
| Protection | Built-in smart BMS；Breaker |
| Communication Port | CAN |
| Warranty Period | Ten years(0.5C charge/Discharge @25°C, 80% DOD) |
